Drum   Diameter

~￠540mm

Drum   Rotation Speed

~6780r/min

Production   Capacity

2000L/H

Separation   Factor

＞12000g

Feed   Inlet Pressure

0～0.1Mpa

Feed   Outlet Pressure

0～0.3Mpa

Operating   Water Pressure

0.2mpa≤p≤0.45mpa

Sludge   Discharge Method

Automatic   sludge discharge (partial sludge discharge or full sludge discharge)

Sludge   Discharge Time and Interval Time

According   to the quality of raw materials, the sludge discharge time is adjustable from   0.01 seconds to 9.99 seconds, and the sludge discharge cycle is adjustable   from 1 minute to 240 minutes.

Motor   Power

18.5KW

Bearing

SKF   separator bearing

Transmission   Mode

Gear   transmission structure regulated by frequency converter

Weight

~1960kg
